An engineering approach that might surprise you

Consider the simple act of measuring the force multiplier of a simple pulley. We say a simple block and tackle pulley arrangement gives us a two-to-one mechanical advantage because the weight being lifted is being lifted twice, even though we are only pulling once.

images

Photo: A simple "block and tackle" pulley system
Click photo for a larger image

But this ignores the friction in the pulley and the weight of the rope itself. That is why engineers tend to run thought experiments using “frictionless pulleys” and “massless ropes.” The resulting answer is inexact, but good enough to make design decisions.

So if you ever discover something about your airplane the designers didn't know, let them know. But understand that sometimes you have to make an assumption or two to get anything off the drawing board.
